UOTEK UT-6011 Series 10/100M to 1 Ports RS-485/422 Serial Device Server

Regular price $33.49 Sale price $38.00 Unit price per
Tax included. Shipping calculated at checkout.
  • CPU: 25MHz
  • Memory: data cache space per port ≥ 2KB
  • Network port: RJ45 interface 10/100M (surge 10/700us common mode: 1000V/differential mode 500V) auto- MDI/MDI-X
  • Network protocol: IP, ICMP, UDP, TCP
  • System support: Windows/ Xp/2003/win7/win8/win10 32/64bit
  • Operation modes: TCP SERVER, TCP CLIENT, UDP Modbus SERVER master mode, Modbus CLIENT master mode, Modbus SERVER slave mode, Modbus CLIENT slave mode
  • Number of hosts: can support 2 hosts connected at the same time
  • Configuration method: serial port configuration tool
  • Number of serial ports:  5.08-5PIN terminal
  • Serial port protection: RS-485/422 surge 10/700us, common mode / differential mode 0.5KV
  • Baud rate: 100-921600bps
  • Parity bits: None, Odd, Even, Mark, Space
  • Data bits: 8
  • Stop bits: 1,2
  • Flow control: RTS/CTS
  • Supply voltage: 5V(4.75~5.25V)
  • Operating current: 158mA
  • Power supply interface: 5.08mm 2Pin terminal block and DC socket
  • Operating temperature: -40~85°C
  • Storage temperature: -40~85°C
  • Relative humidity:5~95%RH,(no condensing)
