UOTEK UT-60020G 20-Port Full Gigabit Unmanaged Ethernet Switch

>>Standards
IEEE802.3, IEEE802.3u, IEEE802.3z, IEEE802.3ab

>>Ports
Fiber port: 1000Base-X(SC/ST/FC/SFP slot)
RJ-45 port: 10/100/1000Base-T(X), auto MDI/MDI-X

>>Transmission Distance
Cat.5e: 100m

>>Fiber Patch Cord
Single-mode: 1,310nm   20/40/60Km
                   1,550nm   80/100/120Km
Multi-mode:   1,310nm   2Km

>>Switching Performance
Forwarding rate: 1,488,095pps
Transmission mode:  store-and-forward
MAC address buffer: 8K
Switching bandwidth: 40G

>>Power Requirement
Voltage input

Option 1: 12/24/48VDC(10.8~52.8VDC)
Option 2: 110/220VAC(88~264VAC)/50-60Hz or 110/220VDC(88~264VDC)

Supports dual power input

>>Power Consumption
Rating power: 5W

>>Mechanical Characteristics
IP rating: IP40
Weight: <1,600g
Installation: DIN-Rail

Dimension: 150×120mm×70mm

>>Environment
Operating temperature: -40~85℃
Storage temperature: -40~85℃
Relative humidity: 0~95%(non-condensing)

>>Industrial Standards
EMI:
FCC Part 15, CISPR (EN55022) class A
EMS:
IEC(EN)61000-4-2(ESD)
IEC(EN)61000-4-3(RS)
IEC(EN)61000-4-4(EFT)
IEC(EN)61000-4-5(Surge)
IEC(EN)61000-4-6(CS)
IEC 60068-2-27(Shock)

IEC 60068-2-32(Freefall)
