UTEK Technology
UT-8814 USB to 4-Port RS-232 Converter
Regular price
$42.78
Sale price
$49.00
Tax included.
Shipping calculated at checkout.
● Standards: USBV1.1, 2.0, RS-232 EIA
● USB signals: VCC, DATA-, DATA+, GND, FG
● RS-232 signals: DCD RXD TXD DTR GND DSR RTS CTS RI
● Working mode: Asynchronous, point to point
● Direction control: Adopts data direction auto control technology, auto control the data transmission direction
● Baudrate: 300-921,600bps, auto detection
● Load capacity: supports point to point
● Transmission distance: RS-232 5m, USB no more than 5m
● Port protection: surge, ±15KV ESD protection
● Connector: USB-A male, DB9 male
● Indicator: TXD, RXD, POWER
● Transmission media: Twisted pair or shielded cable
● Cable length: 1.5m
● Operating temperature: -40℃~85℃, relative humidity 5%~95%
● Supports Win8/Win10/Win2000/2003/2008/2012/XP/Vista/7/8/8.1/10/CE/Mac/Linux
● USB signals: VCC, DATA-, DATA+, GND, FG
● RS-232 signals: DCD RXD TXD DTR GND DSR RTS CTS RI
● Working mode: Asynchronous, point to point
● Direction control: Adopts data direction auto control technology, auto control the data transmission direction
● Baudrate: 300-921,600bps, auto detection
● Load capacity: supports point to point
● Transmission distance: RS-232 5m, USB no more than 5m
● Port protection: surge, ±15KV ESD protection
● Connector: USB-A male, DB9 male
● Indicator: TXD, RXD, POWER
● Transmission media: Twisted pair or shielded cable
● Cable length: 1.5m
● Operating temperature: -40℃~85℃, relative humidity 5%~95%
● Supports Win8/Win10/Win2000/2003/2008/2012/XP/Vista/7/8/8.1/10/CE/Mac/Linux
